Platter
Max Weight on Platter (w/support)
: 4.5 kg
Max Weight on Platter (unsupported)
: 2.3 kg
Spindle
Number
: 4
Max Speed
: 200 °/sec
Max Torque
: 34 Nm
Nose Thread
: 2 3/16 in - 10
Runout Max
: 0.010 mm
Center Height
: 149.23 mm
Collet Size
: 5C
Backlash
: 50 arc-sec
Gear Ratio
: 60:01:00
Indexing
Accuracy (±)
: ± 60 arc-sec
Repeatability
: 10 arc-sec
Resolution
: 0.001 °
Worm Gear Dia
: 71 mm
Max Rotation/Step (with rotary control)
: 999.999 °
General
Power Requirement
: 115 VAC ± 10% @ 15 A
Operating Temp (max ambient)
: 38 °C
Air Requirements
Air Pressure Max
: 10.3 bar
Dimensions - Shipping
Export Crate
: 117 cm x 61 cm x 61 cm
Weight
: 146.0 kg
